Manual Bar Screen

Simple, rugged stainless steel coarse bar screen for STPs, ETPs and drains, with bar spacing from 6 mm upwards.

Low-cost screening for smaller plants and standby channels

Adroit’s Manual Bar Screen is a simple and reliable way to remove floating and solid waste from sewage, industrial effluent and storm water. There are no motors or moving parts. The screen is made to fit your channel, installed at an incline and cleaned with a rake.
We make manual bar screens in SS 304 or SS 316 with bar spacing from 6 mm upwards. They are commonly used as the main screen in smaller STPs and ETPs, and as the standby or bypass screen alongside a mechanical screen in larger plants.

Where a manual bar screen fits

Application

The first step in treating wastewater is to remove rags, plastics and floating debris that could damage pumps and obstruct downstream units. In plants where the flow and debris load are low to moderate, a manual bar screen provides a simple screening solution with lower initial investment than a mechanical screen.
In larger plants, a manual screen is usually installed in the bypass channel next to the mechanical screen, so the plant keeps running while the mechanical screen is being serviced.

How a manual bar screen works

Operation

The screen is a row of parallel bars fixed in a frame, installed across the channel at an inclined angle so the operator can rake it easily. Water passes between the bars and debris larger than the bar spacing is held on the screen.

An operator cleans the screen at regular intervals with a rake, pulling the debris up the bars on to a platform or tray at the top, from where it is removed for disposal. The bar spacing decides what size of debris is removed.

Where manual bar screens are used

Application areas

Municipal and industrial treatment plants

Main inlet screen in small plants; bypass screen in large ones.

Power plants and cooling water systems

Removes larger debris before pumps.

Food processing industries

Simple pre-screening of process wastewater.

Textile and paper industries

Removes rags, fibres and coarse debris from effluent.

Storm water and drainage systems

Screens floating waste in drains and nalas.

Why choose Adroit's manual bar screen

Features & advantages

Stainless steel construction

SS 304 or SS 316 for durability and corrosion resistance in wastewater.

Effective screening

Removes rags, plastics, floating solids and other debris before they reach pumps.

Easy cleaning

Cleaned with a simple rake; no power, no controls.

Made to your channel

Bar spacing, bar size, width and depth are made to suit each site.

Low cost to buy and run

Low initial investment and very low maintenance compared with mechanical screens.

Manual bar screen dimensions and construction

Dimensions & manufacturing

6 mm and above

Bar spacing

Stainless Steel 304 / 316

Material of construction

As per client requirement

Channel width and depth

Inclined, in channel

Installation
