Batchflow® SBR

Sequencing batch reactor (SBR) system with a floating weir decanter built specifically for SBR plants.

Sequencing batch reactor (SBR) system for municipal and industrial wastewater

Batchflow® SBR is Adroit’s sequencing batch reactor (SBR) system for sewage and industrial effluent treatment. In an SBR, biological treatment and settling take place in the same basin in timed cycles, so a separate secondary clarifier is generally not required within the SBR process configuration.

The component that decides SBR effluent quality is the decanter, because all treated water leaves through it. Batchflow® uses a floating weir decanter designed specifically for SBR plants. It collects water from below the surface, keeping foam, scum and floating material out of the effluent, and moves down with the water level while staying as far as possible from the settled sludge.

Where Batchflow® SBR is used

Application

Batchflow® SBR is used in municipal sewage treatment plants and industrial effluent treatment plants designed around the sequencing batch reactor process.

How the Batchflow® SBR cycle works

Operation

Each SBR basin runs through the same sequence of steps, over and over:

Fill. Screened and degritted wastewater enters the basin.

React. The basin is aerated so that bacteria break down the organic load.

Settle. Aeration stops and the sludge settles, leaving a layer of clear treated water at the top.

Decant. The Batchflow® floating weir decanter draws off the clear water. It is connected through a flex joint that lets it move freely in the vertical plane between the high and low water levels. Water enters from below the surface, so foam, scum and floatables stay behind, and the decanter keeps the maximum distance from the settled sludge so that sludge does not enter the outlet pipe.

Where Batchflow® SBR is installed

Application areas

Municipal sewage treatment plants

STPs based on the sequencing batch reactor process.

Industrial effluent treatment plants

ETPs based on the sequencing batch reactor process.

Why choose Batchflow® SBR

Features & advantages

Decanter designed for SBR

The floating weir decanter is built specifically for SBR plants.

Clear effluent, no scum

Sub-surface withdrawal keeps foam, scum and floatables out of the treated water.

Sludge stays in the basin

The decanter keeps the maximum distance from settled sludge during decanting.

Free movement with water level

Flex joint allows vertical articulation between high and low water levels.

Maintenance-free decanting

Meets the requirement for maintenance-free decanting in SBR plants.

No separate secondary clarifier

Treatment and settling happen in the same basin.

Design basis

Dimensions & manufacturing

Sequencing batch reactor: fill, react, settle, decant

Process

Floating weir decanter with flex joint

Decanter

From below the water surface

Withdrawal

Flow, influent quality, treated water quality required

Design inputs
